LP Gas

Emergency Cylinder Adapter

• 1″-20 Female Cylinder Thread x Male Quick Connect
• Used for connecting gas bottle cylinders to new style POL hose connections

Part Number: 07-30205

Quick Connect Branch Tee

• Male Quick Connect x Female Quick Connect x 1″-20 Male Cylinder Thread
• Includes green quick connect and brass cylinder thread cap
• WARNING: Gas lanterns are not to be connected with quick connect applications
• Instructions included

Part Number: 07-30215

3/8" Female Flare to 1/4" MPT Connector

•3/8″ Female Flare to 1/4″ MPT
•Used to connect two LP Hoses or fittings
•*Not for potable use (contains lead)

Part Number: 07-30225

Quick Connect Tailpiece

• 1-5/16″ Female ACME Quick Connect x 1/4″ MPT
• 100,000 BTU
• UL approved
• Black quick connect handle

Part Number: 07-30265

Quick Connect Tailpiece

• 1-5/16″ Female ACME Quick Connect x 1″-20 Cylinder Thread
• 200,000 BTU
• UL approved
• Green quick connect handle

Part Number: 07-30275

Quick Connect Tailpiece

• 1-5/16″ Female ACME Quick Connect x 1/4″ MPT
• 400,000 BTU
• UL approved
• Green quick connect handle

Part Number: 07-30285

Vertical Regulator Cover

• Used with 07-30365 Regulator
• Plastic, one piece cover
• Easy, snap-on installation

Part Number: 07-30295

Horizontal Regulator Cover

• Used with 07-30385 Regulator
• Plastic, one piece cover
• Easy, snap-on installation

Part Number: 07-30305

Auto Changeover Regulator Cover

• Used with 07-30395 Regulator
• Plastic, one piece cover
• Easy, snap-on installation

Part Number: 07-30315

High Pressure Regulator



KEY FEATURES

• 1/4″ FPT Inlet x 1/4″ FPT Outlet
• 500,000 BTU/Hr or 30 PSIG based on 100 PSIG inlet
• Primary use, dual bottle with distant separation applications
• Ideal use where PSIG rather than W.C. is needed

https://jrproducts.net/wp-content/uploads/2018/05/07-30325.mp4

Part Number: 07-30325

Low Pressure Regulator

• 1/4″ FPT Inlet x 3/8″ FPT Outlet
• Drip lip vent above outlet
• 175,000 BTU/Hr based on 25 PSIG inlet & 9″ W.C.
• Primary use, portable appliances

Part Number: 07-30335

Z Regulator Bracket

• Used for mounting LP gas regulators on flat surfaces
• Normally uses two (2) for installation
• Includes regulator screws

Part Number: 07-30345

Square Regulator Bracket

• Used for mounting regulator on flat surfaces
• Includes regulator screws
• Replaces the use of two (2) Z brackets

Part Number: 07-30355

Low Pressure Two-Stage LP Gas Regulator

• Combines both a high pressure first stage and a low pressure second stage regulator into one unit
• Ideally designed for RV applications, these regulators ensure a smooth and continuous flow of gas to all appliances
• Above Outlet Vent Position
• 1/4″ FPT Inlet
• 3/8″ FPT Outlet
• 225,000 BTU/Hr Capacity
• Zinc Die Cast
• Molded Rubber Diaphragms
• UL Approved
• 2nd Stage Relief Mechanism Per UL 144
• Adjustable Screw and Dust Cap Design
• Powder Coated

Part Number: 07-30365

Low Pressure Two-Stage LP Gas Regulator

• Combines both a high pressure first stage and a low pressure second stage regulator into one unit
• Ideally designed for RV applications, these regulators ensure a smooth and continuous flow of gas to all appliances
• 9:00 Vent Position
• 1/4″ FPT Inlet
• 3/8″ FPT Outlet
• 225,000 BTU/Hr Capacity
• Zinc Die Cast
• Molded Rubber Diaphragms
• UL Approved
• 2nd Stage Relief Mechanism Per UL 144
• Adjustable Screw and Dust Cap Design
• Powder Coated

Part Number: 07-30385
